Foundry FLS624

FOUNDRY FLS624 20 x 10/100/1000 Mbps ports plus 4 combination RJ45/SFP Gigabit Ethernet (copper or fiber) ports. The switch includes 3 slots for optional 1 port 10GbE modules

Device TypeSwitch - 24 ports - L3 - managed
SubtypeGigabit Ethernet
Ports24 x 10/100/1000 + 4 x shared SFP
Authentication MethodRADIUS, Secure Shell v.2 (SSH2), TACACS
MAC Address Table Size16K entries
Authentication MethodRADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2)
Encryption AlgorithmAES
Routing ProtocolOSPF, RIP-1, RIP-2, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, IGMPv3, MLDv2, MLD
ManufacturerBrocade Communications
POWER DEVICE
Nominal VoltageAC 120/230 V
Power Consumption Operational63 Watt
Typeinternal power supply
NETWORKING
Cabling TypeEthernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T
MAC Address Table Size16K entries
Subcategorynetwork hubs and switches
SubtypeGigabit Ethernet
Form Factordesktop
Typeswitch
Connectivity Technologywired
Advanced SwitchingLayer 3
FeaturesAccess Control List (ACL) support, DHCP support, DiffServ support, Digital Optical Monitoring (DOM) support, DoS attack prevention, Foundry Discovery Protocol (FDP) support, IGMP snooping, IPv6 support, Jumbo Frames support, Link Fault Signaling (LFS), MAC address filtering, MLD snooping, Metro Ring Protocol (MRP) support, PIM-SM snooping, Per-VLAN Spanning Tree (PVST), Quality of Service (QoS), RADIUS support, Rapid Spanning Tree Protocol (RSTP) support, Remote Fault Notification (RFN), SNTP support, SSH support, Spanning Tree Protocol (STP) support, Super Aggregated VLAN (SAV), Syslog support, Trivial File Transfer Protocol (TFTP) support, VLAN Stacking, VLAN support, Virtual Cable Test (VCT) technology, Virtual Route Redundancy Protocol (VRRP) support, Virtual Switch Redundancy Protocol (VSRP) support, Weighted Round Robin (WRR) queuing, auto-negotiation, auto-uplink (auto MDI/MDI-X), event log, layer 2 switching, layer 3 switching, port mirroring,
