Cisco WS-C3560-24TS-S

  • $30.00
    Unit price per

Used: 1 available


Cisco WS-C3560-24TS-S Catalyst 3560 24 10/100 + 2 SFP IPB Image Switch

• 24 Ethernet 10/100 ports and 2 SFP-based Gigabit Ethernet ports
• 1RU fixed-configuration, multilayer switch
• Enterprise-class intelligent services delivered to the network edge
• IP Base software feature set (IPB)

GENERAL
Subtype: Fast Ethernet
Ports: 24 x 10/100 + 2 x SFP
Authentication Method: Kerberos, RADIUS, Secure Shell v.2 (SSH2), TACACS+
RAM128 MB
MAC Address Table Size: 12K entries
Authentication Method: Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Status Indicators: Port status, port transmission speed, port duplex mode, power, link OK, system
Routing Protocol: RIP-1, RIP-2, static IP routing, RIPng

CAMERA
Installed Size: 32 MB

POWER DEVICE
Nominal Voltage: AC 120/230 V
Frequency Required: 50/60 Hz
Power Consumption Operational: 45 Watt
Type: internal power supply

NETWORKING
Cabling Type: Ethernet 100Base-TX, Ethernet 10Base-T
MAC Address Table Size: 12K entries
Subcategory: network hubs and switches
Subtype: Fast Ethernet
Form Factor: desktop
Type: Switch
Connectivity Technology: wired
Advanced Switching: Layer 3
Features: Access Control List (ACL) support, DHCP server, DHCP snooping, DHCP support, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, IGMP snooping, IP-routing, MLD snooping, MPLS support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), Time Domain Reflectometry (TDR), Trivial File Transfer Protocol (TFTP) support, VLAN support, Virtual Route Forwarding-Lite (VRF-Lite), auto-negotiation, auto-sensing per device, auto-uplink (auto MDI/MDI-X), full duplex capability, layer 2 switching, layer 3 switching, manageable, traffic shaping, trunking
Compliant Standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ports Qty: 24
Manageable: Yes
Routing Protocol: RIP-1, RIP-2, RIPng, static IP routing
Switching Protocol: Ethernet
Remote Management Protocol: HTTP, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH-2, Telnet
Communication Mode: full-duplex, half-duplex

MISCELLANEOUS
MTBF: 326100 hour(s)
Height (Rack Units): 1 m

POWER
Features: Redundant Power System (RPS) connector
Features: Redundant Power System (RPS) connector

INTERFACE PROVIDED
Qty: 1, 2, 24
Connector Type: SFP (mini-GBIC)
Comments: management

RAM
Installed Size: 128 MB

ENVIRONMENTAL PARAMETERS
Min Operating Temperature: 32 °F
Max Operating Temperature: 113 °F
Humidity Range Operating: 10 - 85%

DIMENSIONS & WEIGHT
Width: 17.5 in
Depth: 11.8 in
Height: 1.7 in
Weight: 8.6 lbs

SOFTWARE
Type: Cisco IOS IP Base

WS-C3560-24TS-S
