INTENO XG6846

New (Sealed): 10 available

INTENO XG6846, AES68400G95L106L European power manageable non-blocking Gigabit Ethernet Layer 2 CPE with one CAT5 WAN (EXT1) ,
one SFP fiber WAN port and 4 Gigabit LAN ports.
The 4 LAN ports are color marked to simplify end user support.
IGMP Snooping for IPTV is supported for all LAN ports and is enabled by default.
Dual WAN
SFP is inserted in the SFP tray => CAT5 WAN (EXT1) is used as LAN port 5.
No SFP is inserted CAT5 WAN => (EXT1) is used as WAN port.
XG6846 have a CPU which is used for IP management and for controlling the L2 switch.
The CPU is connected to the L2 switch on a separate Ethernet port.
The 6846 have a static memory (FLASH) for storage of configuration and firmware.
A USB 2.0 port is located beside the LAN ports.
