Fortinet FG-3000D

Fortinet - FG-3000D - Fortinet FortiGate FG-3000D Network Security/Firewall Appliance - 1000Base-X, 10GBase-X - 10 Gigabit Ethernet - AES (256-bit), SHA-1 - 16 Total Expansion Slots - 2U - Rack-mountable

Overview:
Today’s data centers require security appliances that deliver exceptional performance, deployment flexibility and extensive security features, to protect the most demanding network environments. The FortiGate 3000D device is ideally suited for network segmentation and internal network threat protection in data centers with its 16 10 GE interfaces.
10 Times Data Center Firewall Performance
The FortiGate 3000D appliance provides up to 80 Gbps of firewall throughput through the use of innovative FortiASIC processors and the latest generation of multi-core CPUs. Impressive consolidated security performance and support for a variety of configurations ensure that essential security functions keep up with the rest of your network.
Future-proof Security
The system also provides technologies that include robust networking capabilities and extensible security features, all managed from an intuitive management console with deep insight offerings, enabling you to keep pace with your evolving network.
Features & Benefits
Industry-leading 10x data center firewall offers exceptional throughput and ultra-low latency
Highly available and Virtual Domain (VDOM) support for multi-tenant data center environment
Integrated high-speed 10 GE+ port delivers maximum flexibility and scalability
Intuitive management interface enables broad and deep visibility and control
NSS Labs Recommended consolidated security delivers top-rated protection

Interfaces and Modules
10 GE SFP+ / GE SFP Slots 16
GE RJ45 Management Ports 2
USB Ports (Server) 1
Console Port 1
Internal Storage 480 GB
Included Transceivers 2x SFP+ (SR 10GE)
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte, UDP) 80 / 80 / 50 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) 80 / 80 / 50 Gbps
Firewall Latency (64 byte, UDP) 3 µs
Firewall Throughput (Packet per Second) 75 Mpps
Concurrent Sessions (TCP) 50 Million
New Sessions/Second (TCP) 400,000
Firewall Policies 100,000
IPsec VPN Throughput (512 byte) 50 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 20,000
Client-to-Gateway IPsec VPN Tunnels 64,000
SSL-VPN Throughput 8 Gbps
Concurrent SSL-VPN Users (Recommended Maximum) 30,000
IPS Throughput 14 Gbps
Antivirus Throughput 5.7 Gbps
Virtual Domains (Default / Maximum) 10 / 500
Maximum Number of FortiAPs (Total / Tunnel Mode) 4,096 / 1,024
Maximum Number of FortiTokens 5,000
Maximum Number of Registered FortiClients 20,000
High Availability Configurations Active/Active, Active/Passive, Clustering
Dimensions amd Power
Height x Width x Length (inches) 3.5 x 17.4 x 21.9
Height x Width x Length (mm) 88 x 442 x 555
Weight 37.5 lbs (17.0 kg)
Form Factor 2 RU
AC Power Supply 100–240V AC, 50–60 Hz
DC Power Supply (FG-3000D-DC) 40.5–57V DC
Power Consumption (Average / Maximum) 310 W / 427 W
Heat Dissipation 1457 BTU/h
