Cisco WS-C3650-24TD-S

Cisco WS-C3650-24TD-S Standalone with Optional Stacking 24 10/100/1000 Ethernet and 2x10G Uplink ports, with 250WAC power supply, 1 RU, IP Base feature set

WS-C3650-24TD-S

Technical Specifications
Capacity
Type : IPv4 routes
Value : 24000
Type : NetFlow entries
Type : Switched virtual interfaces (SVIs)
Type : Virtual interfaces (VLANs)
Value : 1000
Dimensions & Weight
Depth : 17.6 in
Height : 1.7 in
Weight : 15.15 lbs
Width : 17.5 in
Environmental Parameters
Humidity Range Operating : 5 - 96% (non-condensing)
Max Operating Temperature : 113 °F
Max Storage Temperature : 158 °F
Min Operating Temperature : 23 °F
Min Storage Temperature : -40 °F
Flash Memory
Installed Size : 2 GB
Header
Brand : Cisco
Compatibility : PC
Manufacturer : Cisco Systems
Model : 3650-24TD-S
Packaged Quantity : 1
Product Line : Cisco Catalyst
Interface Provided
Comments : Management
Type : Serial (console)
Comments : Uplink
Connector Type : SFP
Qty : 2
Type : 1000Base-X
Connector Type : RJ-45
Qty : 24
Type : 1000Base-T
Connector Type : SFP+
Type : 10GBase-X
Connector Type : Type A
Qty : 1
Type : USB
Connector Type : Type B
Type : Management (mini-USB)
Type : Management (Gigabit LAN)
Miscellaneous
Authentication Method : RADIUS, Secure Shell (SSH), TACACS+
Color Category : Black
Compliant Standards : BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A, GOST, ICES-003 Class A, IEC 60950-1 Second Edition, ISO 7779, KCC, KN22 Class A, KN24, NOM, RoHS, UL 60950-1 Second Edition, VCCI Class A
Height (Rack Units) : 1
MTBF : 661,800 hours
Rack Mounting Kit : Included

Networking
Advanced Switching : Layer 3
Compliant Standards : IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Connectivity Technology : Wired/Wireless
Features : Access Control List (ACL) support, ARP support, DHCP snooping, Dynamic ARP Inspection (DAI), EIGRP Stub Routing, Energy Efficient Ethernet, Flexible NetFlow (FNF), IGMP snooping, Layer 2 switching, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Trunking, Uni-Directional Link Detection (UDLD), VLAN support
Form Factor : Desktop, Rack-mountable
Jumbo Frame Support : 9198 bytes
MAC Address Table Size : 32000 entries
Manageable : Yes
Ports Qty : 24
Power Over Ethernet (PoE) : PoE+
Remote Management Protocol : CLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
Routing Protocol : OSPF, RIP-1, RIP-2, RIPng, Static IP routing
Stackable : Stackable
Status Indicators : Active, Port duplex mode, Port transmission speed, Status, System
Subcategory : Network hubs and switches
Subtype : Gigabit Ethernet
Type : Switch
Performance
Type : Forwarding performance
Value : 65.47 Mpps
Type : Switching capacity
Value : 88 Gbps
Ports
Qty : 24
Type : 10/100/1000
Ports (2nd)
Qty : 2
Type : 10 Gigabit SFP+
Power Device
Frequency Required : 50/60 Hz
Hot-Plug : Hot-plug
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : AC 120/230 V
Power Provided : 250 Watt
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with optional power supply)
Type : Internal power supply
